Johnson/Evinrude, OMC Parts Finder. Select your engine. The Outboard Marine Corporation is the worlds largest manufacturer of outboard motors. Be prepared for maintenance work with the extensive information found in a Johnson Outboard Service Manual from Wholesale Marine! Same-day shipping available! BRP - Evinrude family! Your purchase comes with the full commitment and support of the BRP. Evinrude outboard engine team. We are confident that your new.
Evinrude E-TEC includes both new technologies and improvements to existing technologies. We've built these technologies onto existing and proven - durable, reliable platforms. For example, our 2-cylinder 40 through 60 horsepower Evinrude E-TEC outboards are built on the mid-section and gear case of the 55 horsepower Commercial series outboards.
In fact, the Commercial outboards are the basis for the outboards the U.S. Navy Seal Teams and U.S. Marine Corps Recon Teams rely upon during their assigned missions. The 3-cylinder 75/90 horsepower Evinrude E-TEC outboards are built on the mid-section and gear case of the 60 degree V4. What does E-TEC stand for? Evinrude E-TEC is the best of both technologies. It provides the quiet, efficiency and cleanliness many customers associate with the 4-stroke outboards, combined with the torque, throttle response, quick acceleration and raw power associated with the 2-stroke outboard.
The technology is considered 2-Stroke, Direct Injection. Evinrude E-TEC in fact, has cleaner exhaust emissions than a 4-stroke, it produces 5 to 10 times less Carbon Monoxide (CO) while idling or trolling. What is the new technology used on Evinrude E-TEC outboards? Evinrude E-TEC uses several new technologies. The most obvious, when looking at an Evinrude E-TEC outboard, is the fuel injector.
It is not a solenoid type injector, like the Evinrude DI models Bombardier began producing for the 2002 model year. This injector design requires less operating current to activate, meaning we are able to use smaller electronics which operate at cooler temperatures. Cooler running electronics equates to durability. The injector has fewer parts and requires fewer tight tolerances, which lowers manufacturing costs. What about the not so obvious technology? What's not obvious about Evinrude E-TEC is what's inside the engine block.
Johnson Manuals Free
Evinrude E-TEC incorporates pistons made from a new alloy, which was developed by NASA. This alloy has proven to be 2 to 3 times stronger at operating temperature than the aluminum alloys pistons are traditionally made with.
The pistons used in the 40 through 60 and the 75/90 are what's known as 'full-skirt' pistons. The internal design of the block (the intake, exhaust and transfer ports) doesn't require machining 'port windows' into the piston. This combined with the new alloy, increase the piston strength and durability. What else have you done to the internal engine components? As stated earlier, there are improvements too. Just as the electronics in our home & office PC's have advanced and become smaller packages, so have the electronics (microprocessor) in our engine management system. The improvements Bombardier initiated to the Engine Management Module (EMM) beginning with 2002 production, such as a 30% thicker pc board and increased cooling for components, have been designed into the EMM for the Evinrude E-TEC outboards.
Additionally, our Engineering Team has incorporated diagnostic LED's into the housing, allowing basic troubleshooting to be performed without diagnostic software. A flexible casing and 60% smaller size complete the package and provide a clean, state of the art, under-hood appearance. What have you done to make the engine so quiet?
Our Engineers designed a new air intake system for these engines. The intake system serves to quiet engine noise. An idle air by-pass tube supplies air to the crankcase at low rpm.
There are no holes machined into the throttle plates, therefore no whistle sound at idle. Innovative baffling in the air silencer box cancels resonant noises. Unlike other manufacturers' outboards, there's no distinctive 'pucka-pucka-pucka' sound of an air compressor, or any belt whine, or any cam chain noise - we don't use them. How much do the E-TEC outboards weigh? A battery is not required to run the rope start models.
However, if you have electrical accessories you want to operate and would like to take advantage of the charging system, the capability is already there. In the event of a battery failure with an electric start model, the engine can be rope started and run without the battery. Earlier I read this engine uses an electric fuel pump. It also has an EMM, which is basically a computer. How is such an electrically dependant motor able to start and run without a battery? Simply put, just like any rope start motor, it generates its own electricity.
To make a comparison, lets discuss the electrical system of a carbureted 25 horsepower 2-stroke for a moment. The basic system design has been around for over 25 years.
Underneath its flywheel is a single charge coil, which produces the voltage to operate the ignition system. There's also a very small stator to provide electrical power for AC Lighting or optional battery charging and, there's a sensor coil which provides the ignition timing. Since Evinrude E-TEC doesn't need a charge coil or a sensor coil (because these functions are controlled by the EMM), a full-diameter stator which uses more windings compared to the 25 model above, is employed. Powerful rare earth magnets are used on the flywheel and, by adapting our patented switching stator technology, the stator is able to generate more current at lower rpm.
The voltage required to turn on and 'boot up' the EMM is delivered in a few milli-seconds. By integrating pulse width modulation technology (which has been used on electric trolling motors for decades), we are able to power up the electric fuel pump and not put an excessive demand on the electrical system while starting the motor. The EMM and fuel pump power up take place in the first third of a revolution of the flywheel.
The EMM then determines crankshaft position via a sensor which 'reads' the flywheel encoder vanes - all of this occurs within the first complete flywheel revolution. This leaves plenty of rope to pull and provides ample voltage to subsequently fire the injectors and ignition and get the engine running.
What propellers do you offer for the Evinrude E-TEC outboards? The Evinrude E-TEC outboards accept our existing line of propellers. We offer a multitude of different props in both aluminum and stainless steel. The stainless prop line includes the 3-blade SST 2 (painted), the 3-blade Viper (polished), the hi-performance Raker (polished) and the 4-blade Cyclone (polished) and Renegade Bass (polished). I read elsewhere on your web site Evinrude E-TEC engines can run up to 50 hours without needing to add oil to the reservoir.
How do you define that 50 hour run period? When the Auto-Winterization feature is activated, the EMM rapidly cycles the oil injector to 'fogs' the engine. When the winterize cycle is complete (about 1 minute), it will automatically shut the engine off.
Once the engine has turned off, turn off the key switch (if equipped), remove the engine from the water or from the flushing device and allow the water to drain from the engine. Your Evinrude E-TEC is ready to be placed into storage. The only additional item we recommend is to remove the propeller and inspect the propshaft and seal to ensure there is no fishing line wrapped around it.
Current recommendations are to use a minimum of 87 octane, 89 octane is preferred. There is no additional benefit from using higher-octane fuels, in fact they may cause hard starting conditions in hot weather. If you have an older motor and the owner's manual requires premium fuel, here's why: When these were built, the best oil available was TCW-2 rated, and did not contain the additive package (detergents, carbon preservatives, etc.) which our current oils (XD-30, XD-50 and XD-100) contain today. In that era, premium fuel contained the additive package that helped prevent the formation of internal engine deposits. That's why premium fuels were preferred at the time. Ultimately, in the late 90's the federal government mandated fuel refiners to use the same additive package in all grades of fuel and the premium fuel requirement was dropped. Can I use synthetic oil my OMC Cobra engine?
OMC Cobra's must use straight 30W oils. You cannot use multi-viscosity oil. The additives that are put in multi-viscosity oils cause the oil to break down too fast. This will cause the oil to lose its lubricity characteristics. Remember, a stern drive engine application is much different than a car or truck - the stern drive engine normally sustains a higher running rpm for a longer period of time than a car or truck ( most cars or trucks cruise 2500 rpm's or less, where a stern drive will run 4000 rpm or more ). Using a synthetic oil is acceptable if a straight 30W cannot be found.
The change interval remains every 50 hours! Therefore, given the higher cost of synthetics, this doesn't make them cost effective for use by most boaters. I have some oil that has been sitting on the shelf for a few years. Is it any good? Can I still use it? Eliminating model year designations will not affect a consumer's warranty coverage.
Warranty coverage will begin at the time an Evinrude outboard engine is warranty registered and according to the date of delivery that is referenced on the engine registration. For example, a 50 HP Evinrude E-TEC engine that is sold and warranty registered in May of 2012 will have a three-year limited, non-declining warranty, regardless of when the engine was manufactured. Therefore, eliminating model year will not have any impact on a consumer's warranty coverage. For more details on warranty coverage, please refer to your factory warranty statement. Resale or Trade-In Value. Boat package values are established by organizations like NADA (National Automobile Dealers Association) based upon the model year of the boat. This is standard practice for automobiles, stern drive boat packages and many other applications since the engine is viewed as a component of the entire boat package.
2000 Johnson 225 Outboard Review
With boat values being based completely on the boat's model year, the elimination of model year on Evinrude outboard engines will not affect resale value. When an engine is traded in, the hours of use will determine the trade in value, as hours of use is the marine equivalent to mileage on an automobile. When a significant product change occurs (i.e. When a new model is introduced that replaces a prior version), the model designation will change as needed. By utilizing this process, models with the same code are physically identical, regardless of when they were built.
To view the date of manufacture, reference the serial number label that is located on the engine (see example above). An authorized Evinrude dealer can help you identify the date of manufacture on the engine(s). This is also of particular importance if you are repowering a boat with dual or triple engine applications.
Special deal of the summer Evinrude/Johnson complete lower units with parts installed now available from GLM aftermarket parts. Physical characteristic of gearcase Cross reference charts model number to year and hp. Years 1927 to 1979 years 1980 and up GLM Catalog GLM aftermarket components can be found in the 2016-2017 on-line catalog with exploded view parts drawings. Aftermarket components that GLM manufactures are: Bearing carriers Gear sets Water pump Carburetor sets Replacement gear-cases Thermostats Pistons and piston rings Gaskets Roller and thrust bearing Propeller shaft and drive shafts Seals with special tools GLM Dealer Pricing Web pricing in US funds. Dealers need after-market components for inboard-outboard repairs.
Contact us in company letterhead for our dealer price list. The GLM catalog includes Chris Craft inboard and Crusader. Mercruiser, Volvo-Penta and Cobra outdrives. Chrysler, Mercury and Evinrude/Johnson V6 lower units and components. Includes 202 pages of. On-line parts catalog is comprised of PDF files. In order to view them, you need Acrobat Reader.
Repair Tools Pinion bearing removal Bearing carrier pullers Propeller wrench Pinion nut adapter Prop shaft adapters What's New? Seloc repair manuals for Chrysler, Force, Yamaha, Mariner and Mercury outboards. Mercruiser, Volvo Penta and OMC stern drive books. GLM Maine aftermarket Yamaha parts.
New outboard repair videos: We are a full service provider on Alpha One, Mercruiser, Volvo Penta and all lower units. Please see our Mercury warehouse for tech support drawings for Mercury, Mariner and Force motors. Items we auction on eBay store are bearings, bearing carriers and rebuilt power heads. Fuel systems including carburetors kits, fuel pumps the non VRO type units and a new line of fuel filters.
Replacement V4-V6 gear-cases that includes the 5 degree clutch dog, new heavy duty forward and reverse gears. Tune up sets that include condenser-router, points and distributor cap. We have used drive shafts, lower units, propeller shafts, manuals and propellers.
The main items we sell are lower unit gear case repair tools, water pump sets with impeller included, oil seal and power-head gaskets. Electrical item we list from time to time are ignition coil power packs, rectifiers, starters and shifter boxes. Points, condenser, and plugs we do not normally list on our eBay store. Older used motor boats and RV. Have all so been sold by us. OMC and Mercruiser out-drive components also have been listed for boating enthusiast bidding on eBay.
